- Output: 160kW – 2MW
- Poles: 2,4,6,8,10 & 12 pole
- Speeds: 500 – 3600 RPM
- RPM Frequency: 50 Hz | 60 Hz
- Cast Iron frame size: 315 – 560
- Protection: IP55 | IP56 | IP65 | IP66
- Temperature class: B
- Cooling: IC411
- Insulation class: F
- Duty type: S
- Standards: IEC 60034 - 30 | IEC 60034 - 1-30
- Voltage: 400V Y | 690V Y. Other voltages can be supplied on request
